DC-DC Buck Converter 6~14V to 5V/8A
This 40W high-power DC-DC Buck converter offers a 6~14V input voltage range and up to 5V/8A output. Featuring a small body, high conversion ratio, strong heat dissipation, and large current output, the module is compatible with all 5V mainboards, and can work as an SMD element to be directly soldered onto PCB. With steady output, this buck converter is able to work for a long time without voltage shift, which can be suitable for projects of high requirements like smart homes, small robot car power sources, etc.
Features
- Small in size
- 40W high power output
- Over 96% conversion ratio
- Can be used as SMD component
Specification
- Input Voltage Range: 6V-14V
- Output Voltage: 5V
- Output Current: 0-8A
- Voltage Accuracy: ±1%
- Full-load Output Ripple: ＜30mV
- Conversion Ratio: >96% (12V input, full-load output)
- Static Current: <200uA
- Operating Temperature: 0°C~70°C
Shipping List
Original: $8.40
-65%$8.40
$2.94
Description
This 40W high-power DC-DC Buck converter offers a 6~14V input voltage range and up to 5V/8A output. Featuring a small body, high conversion ratio, strong heat dissipation, and large current output, the module is compatible with all 5V mainboards, and can work as an SMD element to be directly soldered onto PCB. With steady output, this buck converter is able to work for a long time without voltage shift, which can be suitable for projects of high requirements like smart homes, small robot car power sources, etc.
Features
- Small in size
- 40W high power output
- Over 96% conversion ratio
- Can be used as SMD component
Specification
- Input Voltage Range: 6V-14V
- Output Voltage: 5V
- Output Current: 0-8A
- Voltage Accuracy: ±1%
- Full-load Output Ripple: ＜30mV
- Conversion Ratio: >96% (12V input, full-load output)
- Static Current: <200uA
- Operating Temperature: 0°C~70°C
