Grove -1.22" IPS Display (240 x 240)

This 1.22" IPS display uses In-Plane-Switching (IPS) technology with a 240 x 240 pixel resolution and 65k RGB colours, giving wider viewing angles and making images more vibrant. It has input voltages of 3.3V or 5V and is powered by the ST7789 driver IC.

It is supported by an open-source driver library and example code, making it easy to use for projects like digital displays, gaming consoles, and smart home systems.

Features

• 1.22" IPS Display: Offer 240 x 240 resolution, and provide full-view angle
• Simplified IPS Interface: Only requires SCK and SDA for connection to the main controller
• Rich Color Display: Enhance vibrant images with RGB colour, be able to show up to 65k colours
• Wide Operating Temperature: Functioning well at the range of -20 to 70 degrees makes it suitable for various environments
• Compact and Flexible: It has a 4-pin Grove interface for easy microcontroller connection and supports both 3.3V and 5V power supply
• Product Number: Seeed 104020268

Specifications

Interface	Serial SPI with SCK and SDA connections to the main controller
Resolution	240 x 240 pixels
Display Technology	In-Plane-Switching (IPS) technology
Colour	Up to 65k colours with RGB display
Size	Screen: 24.76 x 26.8mm, circuit board: 40 x 40mm
Input Voltage Range	3.3V or 5V
Driver IC	ST7789 with open-source driver library and example code
Operating Temperature	-20 to 70 degrees Celsius

Resources

• Project Wiki
• Eagle File
• ST7789 Spec

Pinout

Package Contents

• 1x Grove 1.22" IPS Display
• 1x Grove Connector
