Mini Scales Unit (HX711)
The Mini Scales Unit is a compact integrated weighing module designed for precision measurement in applications like scientific experiments and industrial production. It features a 5kg weighing sensor paired with an HX711 ADC acquisition chip and a protocol conversion MCU, which together enable the direct output of weighing results. The unit is powered by an STM32F030F4P6 microcontroller and utilises the I2C communication protocol, allowing it to support collaborative operations with multiple modules.
Additional functionalities include an SK6812 RGB programmable LED indicator light and a function button, which simplify tasks like zero calibration and tare adjustment for users. It is also designed for easy installation, featuring a reserved M3 nut fixing hole at the top to accommodate various mounting needs. This mini-weighing unit combines essential weighing technologies and user-friendly features, making it versatile for diverse precision weighing tasks.
Need a scale that can take more weight? Find our 20kg unit here
Features
- STM32F030F4P6@32 bit ARM Cortex-M0 processor
- I2C communication, multiple devices can be used in parallel at the same time
- SK6812 RGB
- Press key to clear and tare
- Weighing up to 5KG
- Programming platform: Arduino, UIFlow, python, etc
Specifications
| Sensor ADC Detection Chip | HX711 |
| MCU | STM32F030F4P6@32 bit ARM Cortex-M0 processor |
| I2C Address | 0x26 |
| LED | SK6812 RGB |
| Button | For zero calibration and peeling adjustment |
| Range | 5KG |
| Bottom fixing nut specifications | M3 |
| Product Size | 40 x 24 x 18mm |
| Package Size | 136 x 92 x 24mm |
| Product Weight | 15.3g |
| Package Weight | 22g |
Resources
Package Contents
- 1x MiniScales Unit
- 4x Nut M3 (hexagonal 6 x 2.25mm)
- 1x HY2.0-4P Cable (20cm)
